Optical System
Voltage: AC100-240V, 50/60Hz
Power: 480W
Light Source: Customized 380W
Lumens: 500,000 @ 10 meters
Dynamic Effects System
Focus Adjustment: 0-100% linear smooth
Dimmer: 0-100% linear dimming
Optics: 165mm high-precision
Strobe: Dual-system (0.5-14Hz, Random/Pulse)
Color Wheel: 14 colors + white (half-color, bidirectional rotation, rainbow effect)
Fixed Gobo Wheel: 14 fixed gobos + white (jitter effect)
Prisms: 6 + 8 + 24 + 48-facet prisms (adjustable rotation speed)
Movement & Control
X/Y Motors: Three-phase stepper (high-speed)
Scan: Pan 540°, Tilt 270° (auto-calibration)
Control Channel: 16/20 channels
Control Mode: DMX512, Random, Sound-activated, Auto
User Manual
Power Cable
XLR Cable
Omega
Flightcase (Optional)
