Optical System

Voltage: AC100V - 240V, 50/60Hz
Power: 480W
Light Source: Customized 380W
Average Life: 2000 Hours
Lumens: 500,000 @ 10 meters
Focus Adjustment: 0 - 100% linear smooth focus adjustment

Dynamic Effects System

Dimmer: 0-100% linear dimming
Color Wheel: 14 colors + white, half - color effect, bidirectional rotation, rainbow effect with adjustable speed
Fixed Gobo Wheel: 14 fixed gobos + white, gobo jitter effect
Prisms: (8+24 facet prisms) with adjustable rotation speed
Optics: 165mm high - precision
X/Y Motors: Three - phase stepper motors are used, with faster speed, more power and quieter operation
Control Channel: 16 / 20 channels
Control Mode: DMX 512/Random/Sound activated/Auto
Display: LCD screen, can be displayed upright or inverted, with Chinese and English switching

Movement & Control
Scan: Pan: 540°/2.0 seconds, Tilt: 270°/1.0 seconds. It has an automatic calibration and positioning function
Strobe: Dual - strobe structural design, adjustable from 0.5 to 14 times per second, Random strobe and pulse strobe can be selected
Appearance: High temperature resistant plastic shell
