Optical System

Voltage: AC100V - 240V, 50/60Hz
Power: 550W
Light Source: USHIO 382W bulb
Optics: 152mm
Beam Angle: 2°

Advanced coated optical system for high efficiency

Dynamic Effects System

Focus Adjustment: 0-100% linear smooth focus adjustment

Dimmer: 0-100% linear dimming

Strobe: Dual-strobe (0.5-14Hz), Randin strobe and pulse strobe can be selected
Color Wheel: 13 colors + white, half-color effect, bidirectional rotation, rainbow effect with adjustable speed
Fixed Gobo Wheel: 13 fixed gobos + white, gobo jitter effect
Prisms: (8+24 facet prisms) with adjustable rotation speed
X/Y Motors: Three - phase stepper motors are used, with faster speed, more power and quieter operation

Movement & Control
Scan: Pan: 540°, Tilt: 240°. It has an automatic calibration and positioning function
RDM: YES

Control Channel: 16CH
Control Mode: DMX 512/Random/Sound activated/Auto
Display: LCD screen, can be displayed upright or inverted, with Chinese and English switching

Physical Specification

Product Size: 325*261*536mm

N.W.: 14KG
