Optical System
Voltage: AC 100-240V, 50/60Hz
Power: 850W
Light Source: 700W LED module
Luminous Flux: 39000LM
Color Temperature: 9200K
Linear CTO Adjustment: 2700K-6200K
Zoom Range: Linear 5° to 48°
Aperture: 145mm (Advanced multi-layer coated optics)

Dynamic Effects System
Frost: YES
Color Wheel: 7 colors + white
Rotating Gobo Wheel: 7 rotating gobos + white circle
Fixed Gobo Wheel: 9 fixed gobos + white circle
Gobo Dimensions: Plate Ø22.8mm, Gobo Ø17mm, Thickness 1.1mm)
Color Mixing: Independent CMY system
Prism: Rotating 4-facet
Cutting System: 4 independent blades, each blade can be individually closed, rotatable up to 45°
Effect Plate: Water-wave + rotatable effect wheel
Dimmer: Linear dimming adjustment from 0 to 100%
Strobe: Multi-speed strobe effects

Movement & Control
Scan: Pan 540°, Tilt 240° (Auto position correction)
Control Modes: DMX512, Auto, Master-Slave, Sound-activated
RDM: YES
Control Channels: 33 channels

Physical Specifications
IP Rating: IP20
Product Size: 424*304*764mm
Net Weight: 30KG
